Features

• 1400 W 2-way class-D amplifier
• 133 dB SPL Max
• 45 – 20000 Hz Frequency Range
• 90° x 50° constant directivity coverage
• 15″ neodymium woofer, 3.5″ voice coil
• Horn loaded 4.0”neodymium c. driver
• Multiple rigging points

Specification

Acoustical specifications

• FREQUENCY RESPONSE: 45 Hz ÷ 20000 Hz
• MAX SPL @ 1M: 133 dB
• HORIZONTAL COVERAGE ANGLE: 90°
• VERTICAL COVERAGE ANGLE: 50°

Transducers

• COMPRESSION DRIVER: 1.4” neo, 4.0” v.c
• WOOFER: 15” neo, 3.5” v.c

Input/Output section

• INPUT SIGNAL: bal/unbal
• INPUT CONNECTORS: XRL, Jack
• OUTPUT CONNECTORS: XLR
• INPUT SENSITIVITY: -2 dBu/+4 dBu
• MIC. INPUT SENSITIVITY: -32 dBu

Processor section

• CROSSOVER FREQUENCIES: 650 Hz
• PROTECTIONS: Thermal, RMS
• LIMITER: Soft Limiter
• CONTROLS: Volume, Boost, Mic/Line

Power section

• TOTAL POWER: 1400 W Peak, 700 W RMS
• HIGH FREQUENCIES: 400 W Peak, 200 W RMS
• LOW FREQUENCIES: 1000 W Peak, 500 W RMS
• COOLING: Convection
• CONNECTIONS: Powercon IN/OUT

Standard compliance

• CE MARKING: Yes

Physical specifications

• CABINET/CASE MATERIAL: Baltic birch plywood
• HARDWARE: 5 x M10, 4 x quick lock
• HANDLES: 2 Side
• POLE MOUNT/CAP: Yes
• GRILLE: Steel
• COLOR: Black

Size

• HEIGHT: 707 mm / 27.83 inches
• WIDTH: 418 mm / 16.46 inches
• DEPTH: 402 mm / 15.83 inches
• WEIGHT: 24 kg / 52.91 lbs

Shipping informations

• PACKAGE HEIGHT: 760 mm / 29.92 inches
• PACKAGE WIDTH: 480 mm / 18.9 inches
• PACKAGE DEPTH: 460 mm / 18.11 inches
• PACKAGE WEIGHT: 27 kg / 59.52 lbs
