FEATURES
Up to 137 dB Sound Pressure Level
4400W Class-D Bi-Amplification
30-120 Hz linear frequency response
2 x 18″ High Power Woofers
IP Rated Powercon TRUE1 TOP IN/OUT
8 Crossover Presets and 4 Cardioid Presets
ACOUSTICAL SPECIFICATIONS
Frequency Response
30 Hz ÷ 120 Hz
Max SPL @ 1m
137 dB
TRANSDUCERS
Woofer
2 x 18”, 4.0” v.c
INPUT/OUTPUT SECTION
Input signal
bal/unbal
Input connectors
XLR
Output connectors
XLR
Input sensitivity
-2 dBu/+4 dBu
PROCESSOR SECTION
Crossover Frequencies
Selectable
Protections
Thermal, Excurs., RMS
Limiter
Soft Limiter
Controls
Xover, Phase switch, Deep/Punch, Output Delay Setting
POWER SECTION
Total Power
4400 W Peak
Low frequencies
4400 W Peak
Cooling
Convection/Forced
Connections
Powercon TRUE1 TOP IN/OUT
POWER SECTION
Total Power
4400 W Peak
Low frequencies
4400 W Peak
Cooling
Convection/Forced
Connections
Powercon TRUE1 TOP IN/OUT
POWER SECTION
Total Power
4400 W Peak
Low frequencies
4400 W Peak
Cooling
Convection/Forced
Connections
Powercon TRUE1 TOP IN/OUT
SHIPPING INFORMATION
Package Height
600 mm / 23.62 inches
Package Width
1370 mm / 53.94 inches
Package Depth
900 mm / 35.43 inches
Package Weight
86 kg / 189.6 lbs
